Polyester elastomer
Two braids of steel wire
Polyurethane - black - non pinpricked - white ink-jet branding
General hydraulic applications requiring high mechanical protection properties of hose and braid combined with high pressure: construction equipment - hoisting and handling equipments - machine tools
Rugged construction for HD application and prolonged lifetime - Two steel braid offers low volumetric expansion and optimum change in length characteristics - Abrasion resistant
High pressure hose suitable for petroleum synthetic or water based hydraulic fluids in hydraulic systems. Suitable for general fluid power transmissions like earthmoving - forklifts trucks - HD construction machinery - hoisting and handling equipment - high pressure equipment. Two steel braid design offers very high mechanical strength which prolongs lifetime of the hose in harsh conditions. Approved by MSHA - Mine Safety and Health Administration - number IC-305.
-40 °C to 100 °C (-40 °F to 212 °F): limited to 70 °C ( 158 °F) for air and water based fluids
-0,93 bar; -700 mm Hg|-13,5 psi; -27,5 inch Hg
Meets the pressure performance requirements of SAE 100R2.
- TO HYDRAULIC - Part No - 2SB - TWO STEEL BRAIDS ANTIABRASION - Inch Size - DN Size - WP bar / psi - MSHA IC-305 - MADE IN ITALY - www.transferoil.com - Batch No
